Endpoint I/O Monitor w/SenseLink Software
Model: AS11990G-12
Endpoint I/O Monitor w/SenseLink Software
Model: AS11990G-12
Overview
Overview
The AS11990G-12 PAC End Point Remote I/O Monitor with integrated SenseLink™ software provides monitoring and alarm capabilities ensuring factory process control and product quality. The PAC End Point system has flexible I/O features and is compact enough to be mounted close to any data source, making remote monitoring, alarm control and real-time data streaming to factory servers simple.
Technical Specs
- TypePAC Endpoint I/O
- Power ConsumptionDevice: 24VDC, ±10%, 0.5A(max), 0.3A(typical)
AIO Power: Internally powered. No external power required. - ConnectorPower: 3 pin with polarity and locking (mating connector provided)
I/O: D-sub 50 pin female
Network: 10/100BaseT, RJ45 connector - Digital I/ONumber of DI: 1, Active low, internal pull-up to 24VDC
Max DI Current: 30 mA
Number of DO: 1, Dry contact relay, 1A max - Analog InputNumber of Inputs: 4 Differential analog inputs
Input Range: 0 to +10V
Resolution: 16-bit
Filtering: 200Hz ±20%, 6dB/octave Min
Impedance: 10 MΩ - Analog OutputNumber of Outputs: 0
- CommunicationEthernet
- Front Panel IndicatorsNetwork: Status LEDs on RJ45
System Status: System Ready(green), 24VDC Health (Green)
Digital Input/Output Points: DO On/Off Status(Green), DI On/Off Status(Green)
- Operating Temperature0-50°C
- Storage Temperature-40 to 85°C
- Humidity5-85% non-condensing
- Dimensions4.921 x 2.066 x 3.633 in. (125 x 52.5 x 92.3 mm)
- Weight0.661 lb (300 g)
