943 Vacuum Gauge Controller
Overview
The Series 943 displays pressure from 10-10 to 10-2 Torr using a high visibility LED display. Two types of analog output are standard for remote monitoring of pressure. An internal converter provides output that allows a simple log conversion from voltage to pressure over the entire operating range. A fast responding, buffered analog output is also provided. Front panel functions allow the user to disable the high voltage, as well as set a pressure at which the cold cathode will automatically turn off. This prevents the controller from displaying incorrect readings when the pressure goes above the operating range of the sensor.
- Wide pressure measurement range 10-10 to 10-2 Torr
- Digital LED display with set point status indicators
- Displays pressure in Torr or Pascal units
- Functions for disabling the high voltage, and set a pressure for the cold cathode to automatically turn off
Products
| Compare | Description | Drawings, CAD & Specs | Availability | Price | |||
|---|---|---|---|---|---|---|---|
|
Digital Controller, Cold Cathode Vacuum Gauge, 100-120 VAC, 50 Hz, Pascal Readout
$1,270
|
943-A-120V50-PA-PC Digital Controller, Cold Cathode Vacuum Gauge, 100-120 VAC, 50 Hz, Pascal Readout | $1,270 |
|
|||
|
|
Digital Controller, Cold Cathode Vacuum Gauge, 100-120 VAC, 50 Hz, Torr Readout
$1,270
|
943-A-120V50-TR-PC Digital Controller, Cold Cathode Vacuum Gauge, 100-120 VAC, 50 Hz, Torr Readout | $1,270 |
|
|||
|
|
Digital Controller, Cold Cathode Vacuum Gauge, 100-120 VAC, 60 Hz, Pascal Readout
$1,270
|
943-A-120V60-PA-PC Digital Controller, Cold Cathode Vacuum Gauge, 100-120 VAC, 60 Hz, Pascal Readout | $1,270 |
|
|||
|
|
Digital Controller, Cold Cathode Vacuum Gauge, 100-120 VAC, 60 Hz, Torr Readout
$1,270
|
943-A-120V60-TR-PC Digital Controller, Cold Cathode Vacuum Gauge, 100-120 VAC, 60 Hz, Torr Readout | $1,270 |
|
|||
|
|
Digital Controller, Cold Cathode Vacuum Gauge, 220-240 VAC, 50 Hz, Pascal Readout
$1,270
|
943-A-220V50-PA-PC Digital Controller, Cold Cathode Vacuum Gauge, 220-240 VAC, 50 Hz, Pascal Readout | $1,270 |
|
|||
|
|
Digital Controller, Cold Cathode Vacuum Gauge, 220-240 VAC, 50 Hz, Torr Readout
$1,270
|
943-A-220V50-TR-PC Digital Controller, Cold Cathode Vacuum Gauge, 220-240 VAC, 50 Hz, Torr Readout | $1,270 |
|
|||
|
|
Digital Controller, Cold Cathode Vacuum Gauge, 220-240 VAC, 60 Hz, Pascal Readout
$1,270
|
943-A-220V60-PA-PC Digital Controller, Cold Cathode Vacuum Gauge, 220-240 VAC, 60 Hz, Pascal Readout | $1,270 |
|
|||
|
|
Digital Controller, Cold Cathode Vacuum Gauge, 220-240 VAC, 60 Hz, Torr Readout
$1,270
|
943-A-220V60-TR-PC Digital Controller, Cold Cathode Vacuum Gauge, 220-240 VAC, 60 Hz, Torr Readout | $1,270 |
|
Specifications
-
Measurement Range1.0 x 10-10 to 1.0 x 10-2 Torr
1.3 x 10-8 to 1.3 Pa -
Set Point Range2.0 x 10-9 to 9.0 to 10-3 Torr
2.7 x 10-7 to 1.2 Pa -
Resolution1% of indicated decade
-
Operating Temperature5° to 40°C (41° to 104°F)
-
Storage Temperature-10° to 55°C (14° to 104°F)
-
Relative Humidity80% maximum for temperatures less than 31°C, decreasing linearly to 50% maximum at 40°C
-
Altitude2000 m maximum
-
Relays2 independently set, SPDT
-
Relay Contact Rating1 A @ 30 VAC or 24 VDC, resistive load
-
Relay Response50 msec for pressures >10-8 Torr
-
Power Requirements100 to 120 VAC or 220 to 240 VAC, 50/60 Hz, 9 W
-
Weight2.5 lbs. (1.1 kg)
-
DisplayRed LED 7 segments digits 14 mm in height
-
Output Voltage0 to 9 VDC or 1 to 9 VDC, 1 V per decade (logarithmic)
-
ComplianceCE
Resources
Other
- 943 Cold Cathode Vacuum Sensor Declaration of Conformity (100009964) (137.4 kB, PDF)
- 943 RoHS Certificate of Compliance (774.9 kB, PDF)
Drawings & CADs
- 943 Cold Cathode Vacuum Gauge Controller Dimensional Drawing (202.5 kB, PDF)
Literature
- 943 Cold Cathode Vacuum Gauge System (305.7 kB, PDF)
Manuals
- 943 Digital, Vacuum Sensor System Manual (386 kB, PDF)
- 943 Sensor System Pin-outs (23.2 kB, PDF)
