Power Supply, Display, 4 Channel, ±15 VDC

Technical Specs

  • Type
    Power Supply/Readout
  • Display
    3.5- digit 0.56 inch red LED, display is 1 of 4 sequentially selectable
  • Channels
    4
  • Input Signal
    4 x 0 - 5 VDC
  • Gas Correction Factor
    0.1 - 4.0
  • External Set Point
    0 - 5 VDC
  • External ON/OFF
    TTL-compatible
  • Unscaled Signal Output
    4 x 0 - 5 VDC = 0 - 100% of Full Scale
  • Scaled Signal Output
    0 - 2 VDC (max.)
  • Power Supply Output
    ±15 VDC at 1.0 Amp, max. ripple < 10 mV
  • Power Requirements
    VAC ±15%, 50/60 Hz
  • For Use With
    MKS 179, 180, 579, 1179, 1479, 1480, 1559, 1579, 2179, M10M, M100
  • Signal Output Minimum Load Impedance
    10 kOhm/channel
